What is the centre head used for?
|
|
|
|
|
|
|
|
|
|
|
|
|
Shop for Protractor Sets |
|
|
|
|
|
|
|
|
|
|
|
|
|
The centre head is the part of the combination square set which has two “arms”. These “arms” meet along one edge of the ruler, at a 90 degree angle. |
|
|
|
|
|
|
|
|
This means that the angle from one of the “arms” to this edge is 45 degrees. |
|
|
|
|
|
|
|
|
The centre head can be used to determine the centre of circular objects, such as the end of rods. |
|
|
|
|
|
|
|
|
Because the “arms” rest at 90 degrees from each other, they can also be used to determine whether the corner of an object is perfectly square. |
|
|
|
|
|
|
|
|
When placed on the corner of an object with the rule attached, the user can draw a 45 degree angle from that corner. |
|
|
|
|
|
|
